Mosquito Species Composition and Plasmodium vivax Infection Rates on Baengnyeong-do (Island), Republic of Korea

Article information

Korean J Parasito. 2011;49(3):313-316
Publication date (electronic) : 2011 September 30
doi :
1Division of Entomology, Walter Reed Army Institute of Research, 503 Robert Grant Avenue, Silver Spring, MD 20910, USA.
2Force Health Protection and Preventive Medicine, 65th Medical Brigade/USAMEDDAC-Korea, Unit 15281, APO AP 96205-5247, Yongsan Army Garrison, USA.
3Department of Environmental Medical Biology, Yonsei University College of Medicine, Seoul 120-752, Korea.
45th Medical Detachment, 168th Multifunctional Medical Battalion, 65th Medical Brigade, Unit 15247, APO AP 96205-5247, Yongsan Army Garrison, USA.
Corresponding author (
Received 2011 April 05; Revised 2011 June 19; Accepted 2011 June 21.


Vivax malaria is a significant military and civilian health threat in the north of the Republic of Korea (ROK). The island of Baengnyeong-do is the westernmost point of the ROK and is located close to the southwestern coast of the Democratic People's Republic of Korea (DPRK). Mosquitoes were collected using a black light trap on Baengnyeong-do, and Anopheles spp. were assayed by PCR, to identify the species, and screened for sporozoites of Plasmodium vivax. Of a subsample of 257 mosquitoes, Anopheles lesteri was the most frequently collected (49.8%), followed by Anopheles sinensis (22.6%), Anopheles pullus (18.7%), Anopheles kleini (7.8%), and Anopheles belenrae (1.2%). The overall sporozoite rate was 3.1%, with the highest rates observed in An. kleini (15.0%), An. sinensis (5.2%), and An. lesteri (1.6%). No sporozoite positive An. pullus or An. belenrae were observed. The results extend our knowledge of the distribution and potential role in malaria transmission of An. kleini, An. lesteri, and An. sinensis, for an area previously considered to be at a low risk for contracting vivax malaria.

Prior to being eradicated from the Republic of Korea (ROK) in 1979, Plasmodium vivax Grassi and Feletti, the causative agent of vivax malaria, was endemic and widespread throughout the ROK [1,2]. In 1993, vivax malaria reemerged on the Korean peninsula [2,3], and in the ROK, most malaria cases have since been contracted near the demilitarized zone (DMZ) that borders North Korea (Democratic People's Republic of Korea, DPRK) [4-6]. Unique conditions in the vicinity of the DMZ, such as the exposure of large numbers of soldiers to malaria parasites and the unmanaged nature of the environment that encourages mosquito breeding, are thought to exacerbate the malaria situation [2,7]. Little information is available as to how widespread malaria is in the DPRK, what mosquito species are involved in malaria transmission, and the relative abundance and distribution of potential malaria vector populations. Ongoing mosquito surveillance data is available for the ROK [5,6] and parasite rates for different species have been reported [8,9], but few data of a similar nature are available for the DPRK. Anopheles belenrae Rueda, Anopheles pullus Yamada, and Anopheles sinensis Wiedemann have been recorded in the DPRK in 2 provinces (Hwanghae and Pyongyang) by Rueda and Gao [10]. Foley et al. [11] produced ecological niche models for 8 anopheline species using collection location data from the ROK that predicted suitable habitat in the ROK and southern DPRK. An. sinensis is the predominant species collected south of Seoul; however, in malaria risk areas in the north, other species are frequently more common [4,12] and may play a greater role in malaria transmission.

Baengnyeong-do is a 45.8 km2 island located near the Northern Limit Line (Fig. 1). This island is the westernmost point of the ROK, and is 16 km from the DPRK coast. As such, entomological conditions on Baengnyeong-do may more closely reflect those in the southwestern DPRK than the rest of the ROK. We collected mosquitoes from Baengnyeong-do in 2007 to better understand the composition of mosquito species and their potential role in malaria transmission in locations where ROK military are deployed.

Fig. 1

Mosquito collection site () at a cowshed on Baengnyeong-do in the northwest part of the Republic of Korea.

Mosquitoes were collected using a black light trap near a cowshed on 15 July 2007 at Baengnyeong-do, Jinchon-2ri, Baengnyeong-myeon, Ongjin-Gun, Incheon, 37° 57' 24.5'' N 124° 41' 55.5'' E. Specimens were transported to the 5th Medical Detachment, Yongsan Army Garrison, Seoul, ROK, where they were identified to species or Subgroup using a dissecting microscope and standard keys [13,14]. It was impossible to identify members of the An. sinensis Subgroup (An. belenrae, Anopheles kleini, Anopheles lesteri Baisas and Hu, An. pullus, and An. sinensis sensu stricto) by morphological techniques. For members of the An. sinensis Subgroup, the abdomen was separated from the thorax and head of the mosquito to reduce the probability of detecting DNA from parasite oocysts in the midgut. The head and thorax of a subsample of 257 mosquitoes were identified by PCR for species [15,16], and by single step and semi-nested multiplex-PCR to identify P. vivax sporozoite infections [17].

A total of 9,971 female mosquitoes were collected (Table 1), 79.0% of which were Aedes vexans nipponii Theobald, and 8.8% Culex tritaeniorhynchus Giles, the primary vector of Japanese encephalitis virus (JEV) in the ROK. Overall, An. sinensis Subgroup species made up 11.8% of the collections, of which An. lesteri predominated (49.8%), followed by An. sinensis (22.6%), An. pullus (18.7%), An. kleini (7.8%), and An. belenrae (1.2%). Overall, the sporozoite rate for members of the An. sinensis Subgroup was 3.1%, with highest rates in An. kleini (15.0%), followed by An. sinensis (5.2%), and An. lesteri (1.6%). Sporozoite positive An. pullus and An. belenrae were not observed (Table 2). Ae. vexans nipponii, is considered a nuisance mosquito that is not readily attracted to humans. It is an early-season floodwater mosquito whose populations rapidly increase with the flooding of rice paddies or heavy rains [5]. Ae. vexans nipponii is usually collected less frequently than members of the An. sinensis Subgroup in New Jersey light trap catches throughout most of the ROK [4,12,18], but was the most commonly collected species trapped at Baengnyeong-do.

Total numbers of mosquitoes collected by black-light trap near a cowshed in Baengnyeong-do (Island), Incheon, Republic of Korea, on 15 July 2007

Total numbers of malaria infected mosquitoes collected and identified by black-light trap near a cowshed in Baengnyeong-do (Island), Incheon, Republic of Korea, on 15 July 2007

An. lesteri was the most frequently collected anopheline, but is infrequently collected in north Gyeonggi and southern provinces throughout the ROK [9,19]. This species is considered an important malaria vector in China [20], and was found to be infected with P. vivax, albeit at relatively low rates, in the present study. The highest sporozoite rate was observed in An. kleini, and we have found this species infected also in northern Gyeonggi province of the ROK (unpublished data). Laboratory experiments found that An. lesteri and An. kleini produced many sporozoites, whereas An. sinensis and An. pullus produced few sporozoites [21]. However, in another study, An. pullus was observed by ELISA to have sporozoite infections of >1,000 sporozoites (unpublished data). Although no sporozoite positive An. belenrae were found in this study, this species has been reported as positive in other studies [9,18]. Taking into consideration of the extrinsic incubation period of P. vivax, the fact that An. sinensis, An. lesteri, and An. kleini were positive for sporozoites, and the remoteness of the island, these species were biting infected humans on Baengnyeong-do, probably 10 days or more beforehand.

As only one trap catch is reported, these results cannot be assumed to reflect conditions for other times of the year, especially during the latter part of summer when normally higher malaria infection rates are observed. For example, relative species abundance and demographic factors, such as longevity, which may predispose mosquitoes for the growth of sporozoites, varies throughout the mosquito season in the ROK [8] (unpublished data). Also, the presence of sporozoites, while necessary for infection of humans, may not translate to new cases, if the number of sporozoites is low [22]. Data provided by the Korea Centers for Disease Control and Prevention for years 2001-2010 showed that Incheon Metropolitan city, which includes the remote island Banengyneong-do, had the second highest overall mean number of malaria cases reported [23], but with low numbers of malaria cases (7 cases) for 2001-2010 reported in Baengnyeong-do [23]. Baengnyeong-do and possibly nearby areas of the DPRK may be suitable for malaria transmission, although it differs from most of the rest of the ROK in the high frequency of An. lesteri, limited human population movements, and island environmental conditions.

The Incheon Metropolitan city government has plans to increase access and facilities on the island to attract tourists year-round [24]. The likelihood of local malaria transmission suggests that active malaria surveillance to reduce asymptomatic cases, vigilance regarding anti-malarial prophylaxis, and vector control is needed, to minimize the potential for the spread of malaria to visitors and residents of Baengnyeong-do.


Funding for portions of this work was provided by the Armed Forces Health Surveillance Center, Division of Global Emerging Infections Surveillance and Response System, Silver Spring, MD, USA and the National Center for Medical Intelligence, Fort Detrick, MD, USA. This research was performed under a Memorandum of Understanding between the Walter Reed Army Institute of Research and the Smithsonian Institution, with institutional support provided by both organizations. The opinions and assertions contained herein are those of the authors and are not to be construed as official or reflecting the views of the Department of the Army or the Department of Defense.


1. World Health Organization. Synopsis of the world malaria situation, 1979. Wkly Epidemiol Rec 1981;56:145–149.
2. Ree HI. Unstable vivax malaria in Korea. Korean J Parasitol 2000;38:119–138. 11002647.
3. World Health Organization Regional Office for Southeast Asia. Malaria situation in SEAR countries: DPR Korea 2003. WHO SEARO, New Delhi Publishing Ltd.
4. Lee WJ, Klein TA, Kim HC, Choi YM, Yoon SH, Chang KS, Chong ST, Lee IY, Jones JW, Jacobs JS, Sattabongkot J, Park JS. Anopheles kleini, Anopheles pullus, and Anopheles sinensis: Potential vectors Plasmodium vivax in the Republic of Korea. J Med Entomol 2007;44:1086–1090. 18047210.
5. Kim HC, Chong ST, Collier BW, Klein TA. Seasonal prevalence of mosquitoes collected from light traps in the Republic of Korea, 2005. Entomol Res 2009;39:70–77.
6. Kim HC, Chong ST, Nunn PV, McNemee RB, Klein TA. Seasonal prevalence of mosquitoes collected from light traps in the Republic of Korea, 2006. Entomol Res 2009;39:248–256.
7. Klein TA, Pacha LA, Lee HC, Kim HC, Lee WJ, Lee JK, Jeung GG, Sames WJ, Gaydos JC. Plasmodium vivax malaria among U.S. Forces Korea in the Republic of Korea, 1993-2007. Mil Med 2009;174:412–418. 19485113.
8. Oh SS, Hur MJ, Joo GS, Kim ST, Go JM, Kim YH, Lee WG, Shin EH. Malaria vector surveillance in Ganghwa-do, a malaria-endemic area in the Republic of Korea. Korean J Parasitol 2010;48:35–41. 20333283.
9. Rueda LM, Li C, Kim HC, Klein TA, Foley DH, Wilkerson RC. Anopheles belenrae, a potential vector of Plasmodium vivax in the Republic of Korea. J Am Mosq Control Assoc 2010;26:430–432. 21290939.
10. Rueda LM, Gao Q. New records of Anopheles belenrae Rueda (Diptera: Culicidae) in North Korea. Proc Entomol Soc Wash 2008;110:523–524.
11. Foley DH, Klein TA, Kim HC, Sames WJ, Wilkerson RC, Rueda LM. Geographic distribution and ecology of potential malaria vectors in the Republic of Korea. J Med Entomol 2009;46:680–692. 19496442.
12. Kim HC, Klein TA, Lee WJ, Collier BW, Chong ST, Sames WJ, Lee IY, Lee YJ, Lee DK. Mosquito species distribution and larval breeding habitats with taxonomic identification of anopheline mosquitoes in Korea. Entomol Res 2007;37:29–35.
13. Tanaka K, Mizusawa K, Saugstad ES. A revision of the adult and larval mosquitoes of Japan (including the Ryukyu Archipelago and the Ogasawara Islands) and Korea (Diptera: Culicidae). Contrib Am Entomol Inst 1979;16:1–987.
14. Lee KW. A revision of the illustrated taxonomic keys to genera and species of female mosquitoes of Korea 1998. Department of the Army, 5th Medical Detachment, 168th Medical Battalion, 18th Medical Command. p. 40.
15. Wilkerson RC, Li C, Rueda LM, Kim HC, Klein TA, Song GH, Strickman D. Molecular confirmation of Anopheles (Anopheles) lesteri from the Republic of South Korea and its genetic identity with An. (Ano.) anthropophagus from China (Diptera: Culicidae). Zootaxa 2003;(378):1–14.
16. Li C, Lee JS, Groebner JL, Kim HC, Klein TA, O'Guinn ML, Wilkerson RC. A newly recognized species in the Anopheles Hyrcanus group and molecular identification of related species from the Republic of South Korea (Diptera: Culicidae). Zootaxa 2005;(939):1–8.
17. Rubio JM, Benito A, Roche J, Berzosa PJ, Garcia ML, Mico M, Edu M, Alvar J. Semi-nested, multiplex polymerase chain reaction for detection of human malaria parasites and evidence of Plasmodium vivax infection in Equatorial Guinea. Am J Trop Med Hyg 1999;60:183–187. 10072133.
18. Jeong KY, Un S, Lee J, Lee IY, Yong TS, Ree HI. Population dynamics of five Anopheles species of the Hyrcanus group in northern Gyeonggi-do, Korea. Korean J Parasitol 2010;48:351–353. 21234242.
19. Kim HC, Rueda LM, Wilkerson RC, Foley DH, Sames WJ, Chong ST, Nunn PV, Klein TA. Distribution and larval habitats of Anopheles species in northern Gyeonggi Province, Republic of Korea. J Vector Ecol 2011;36:124–134. 21635650.
20. Liu C. Comparative studies on the role of Anopheles anthropophagus and Anopheles sinensis in malaria transmission in China. Zhonghua Liu Xing Bing Xue Za Zhi 1990;11:360–363. 2276188.
21. Joshi D, Choochote W, Park MH, Kim JY, Kim TS, Suwonkerd W, Min GS. The susceptibility of Anopheles lesteri to infection with Korean strain of Plasmodium vivax. Malar J 2009;8:42. 19284634.
22. Golenda CF, Klein T, Coleman R, Burge R, Ward RA, Seeley DC. Depletion of total salivary gland protein in blood-fed Anopheles mosquitoes. J Med Entomol 1995;32:300–305. 7616520.
23. Diseases Web Statistics System. Korea Centers for Disease Control and Prevention (K-CDC) on 15 March 2011. Accessed at

Article information Continued

Fig. 1

Mosquito collection site () at a cowshed on Baengnyeong-do in the northwest part of the Republic of Korea.

Table 1.

Total numbers of mosquitoes collected by black-light trap near a cowshed in Baengnyeong-do (Island), Incheon, Republic of Korea, on 15 July 2007

Species Female (%) Male Total
Ochlerotatus dorsalis (Meigen) 27 (0.3) 0 27
Aedes vexans nipponii Theobald 7,877 (79.0) 88 7,965
Anopheles sinensis Subgroup 1,174 (11.8) 42 1,216
Culex bitaeniorhynchus Giles 2 (< 0.1) 0 2
Culex pipiens Linnaeus 16 (0.2) 6 22
Culex tritaeniorhynchus Giles 873 (8.8) 2 875
Mansonia uniformis (Theobald) 2 (< 0.1) 0 2
Total 9,971 (100.0) 138 10,109

Table 2.

Total numbers of malaria infected mosquitoes collected and identified by black-light trap near a cowshed in Baengnyeong-do (Island), Incheon, Republic of Korea, on 15 July 2007

Species Number identified (%) Sporozoite rate (%)a
Anopheles belenrae 3 (1.2) 0.0
Anopheles kleini 20 (7.8) 15.0
Anopheles lesteri 128 (49.7) 1.6
Anopheles pullus 48 (18.7) 0.0
Anopheles sinensis 58 (22.6) 5.2
Total 257 (100.0) 3.1

Sporozoite rate (%)=(Malaria infected/number identified)×100.
